Volvo diesel generator set
Share This Product:
  • DESCRIPTION
  • INFORMATION
Volvo generator

VOLVO generator set uses diesel engine from Sweden VOLVO PENTA company , Volvo company has more than 120 years of history, is one of the world's oldest engine manufacturers, the production of engines are widely used in power stations, generator set equipment, automobiles, construction machinery,ships and other power parts. It is the ideal power for generating sets.

Engines for power generation applications are reliable and durable to meet the most demanding challenges, whether backup or primary power is required.

The advantages of Volvo generator set

1, Volvo diesel generator set has the characteristics of low fuel consumption, low emission, low noise and compact structure;
2, Volvo diesel generator set has a high loading capacity and fast and reliable cold start performance;
3, Stable operation, less exhaust emissions, low operating costs, compact appearance;
4, Volvo diesel generator sets have reliable performance, high horsepower, green environmental protection, user-friendly safety design, and are favored by users around the world.
Technical specification
Model
HL60GF-HL600GF Type Open / Silent / Trailer /  Container
Prime Power
60-600KW Standby Power
66-660KW
Voltage
400/230V,380/220V,220/110V
Rated frequency
50/60HZ
Rated Speed
1500/1800RPM
Rated power factor
0.8
Phase
3 Start mode
Electronic start
Engine brand
Volvo Alternator brand
Shanhua
Certification
CE and ISO
Source factory
Huali
Customized
Yes
Warranty Period
1 year or 1000 running hours

About Volvo generator set

1, Straight six cylinder, water cooled, exhaust gas turbocharged, four-stroke, intake for water to air cooled (TWD type), or intake for air to air cooled (TAD type), direct injection fuel system;

2, With low inertia supercharger and in-line plunger fuel injection pump, integrated mechanical governor or GAC electronic governor, porous fuel injector composed of the reaction speed injection system, the engine has a very short recovery time within the high load capacity.

3, Wet replaceable cylinder liner, with fire resistance shoulder, can make the cylinder head resistant to high temperature. The cast iron cylinder body optimizes the distribution of force, no excess weight, and the machine is particularly light. The nitrogen-carbon treated crankshaft and transmission gear are suitable for heavy duty operation, and the crankshaft has 7 bearings to reduce the load on the main bearing.

4, The electric heater in the intake manifold can make the engine start quickly and reliably at low temperatures in winter, and can reduce exhaust emissions.

5, The newly designed all-electric injection engine also has: higher reliability, no overhaul time of more than 30,000 hours, reaching the industry's previous level;

6, High altitude power drop less, every rise 1000 meters power drop ≤2.5%;

7, Better step load performance, less speed drop and shorter recovery time;

8, Better cold start performance at low temperature; Large exhaust back pressure.
