No. |
Item \ Model |
M03 |
M04 |
M06 |
M08 |
M10 |
M12 |
|
1 |
Spray range without wind (m) |
30 |
40 |
60 |
80 |
100 |
120 |
|
2 |
Coverage（㎡） |
1425/2850 |
2500/5000 |
7536/11300 |
13400/20000 |
20900/31400 |
30144/45216 |
|
3 |
Total power（Kw） |
8.2 |
10.2 |
27.5 |
31 |
39 |
67.5 |
|
4 |
Fan's power（Kw） |
5.5 |
7.5 |
18.5 |
22 |
30 |
55 |
|
5 |
Pump's power（Kw） |
2.2 |
2.2 |
7.5 |
7.5 |
7.5 |
11 |
|
6 |
Fans quantity (pcs) |
1 |
2 |
1 |
2 |
2 |
2 |
|
7 |
Power supply mode |
AC375V～415V、50Hz（±5％）、3 phase 4 wires /Hydraulic/DC |
AC375V～415V、50Hz（±5％）、3 phase 4 wires /Hydraulic/DC |
AC375V～415V、50Hz（±5％）、3 phase 4 wires /Hydraulic/DC |
AC375V～415V、50Hz（±5％）、3 phase 4 wires /Hydraulic/DC |
AC375V～415V、50Hz（±5％）、3 phase 4 wires /Hydraulic/DC |
AC375V～415V、50Hz（±5％）、3 phase 4 wires /Hydraulic/DC |
|
8 |
Nozzles quantity (pcs) |
39 |
39 |
78 |
90 |
90 |
100 |
|
9 |
Water consumption（m³/h） |
3.2 |
3.2 |
8.5 |
9.5 |
9.5 |
12 |
|
10 |
Pump pressure（Mpa） |
centrifugal 1-1.5Mpa |
centrifugal 1-1.5Mpa |
centrifugal 1.5-2.0Mpa |
centrifugal 1.5-2.0Mpa |
centrifugal 1.5-2.0Mpa |
centrifugal 1.5-2.0Mpa |
|
11 |
Fog particle diameter（µm） |
20～150 |
20～150 |
20～150 |
20～200 |
20～200 |
20～200 |
|
12 |
Horizontal turning degree (adjustable) |
±120∘/±180∘ |
±120∘/±180∘ |
±120∘/±180∘ |
±120∘/±180∘ |
±120∘/±180∘ |
±120∘/±180∘ |
|
13 |
Pitching degree |
﹣10°～45° |
﹣10°～45° |
﹣10°～55° |
﹣10°～55° |
﹣10°～55° |
﹣10°～50° |
|
14 |
Control mode |
Remote controller and intelligent touch panel (optional) |
Remote controller and intelligent touch panel (optional) |
Remote controller and intelligent touch panel (optional) |
Remote controller and intelligent touch panel (optional) |
Remote controller and intelligent touch panel (optional) |
Remote controller and intelligent touch panel (optional) |
|
15 |
Fixing mode |
Mobile, tower, platform |
Mobile, tower, platform |
Mobile, tower, platform |
Mobile, tower, platform |
Mobile, tower, platform |
Mobile, tower, platform |
|
16 |
IP grade |
IP55 |
IP55 |
IP55 |
IP55 |
IP55 |
IP55 |
|
17 |
Noise（dB） |
70db at 7.5m |
70db at 7.5m |
80db at 7.5m |
80db at 7.5m |
82db at 7.5m |
85db at 7.5m |
|
18 |
Working temperature（℃） |
0-50℃ |
0-50℃ |
0-50℃ |
0-50℃ |
0-50℃ |
0-50℃ |
|
19 |
Dimension（mm） |
1555x1098x1699 |
1555x1098x1699 |
1900x1155x2365 |
2000x1155x2360 |
2455x1155x2390 |
3100x1700x2500 |
|
20 |
Weight（Kg） |
540（Electric）/480（hydraulic） |
566（electric）/510（hydraulic） |
1200（electric）/1100（hydraulic） |
1250（electric）/1150（hydraulic） |
1370（electric）/1250（hydraulic） |
2700（electric）/2250（hydraulic） |
|
21 |
Noise control |
Double-wall soundproof |
Double-wall soundproof |
Double-wall soundproof |
Double-wall soundproof |
Double-wall soundproof |
Double-wall soundproof |
|
22 |
Spray ring mode |
Double-spraying |
Double-spraying |
Double-spraying |
Double-spraying |
Double-spraying |
Double-spraying |
|
23 |
Matched generator set（Kw） |
10 |
15 |
50 |
50 |
50 |
100 |
|
24 |
Water supply |
Water pressure：0.01-0.4Mpa
PH：6-8 Suspended solids inside the water≤50ppm
Chloride≤2501㎎/L
Total hardness≤450㎎/L
|
Water pressure：0.01-0.4Mpa
PH：6-8 Suspended solids inside the water≤50ppm
Chloride≤2501㎎/L
Total hardness≤450㎎/L
|
Water pressure：0.01-0.4Mpa
PH：6-8 Suspended solids inside the water≤50ppm
Chloride≤2501㎎/L
Total hardness≤450㎎/L
|
Water pressure：0.01-0.4Mpa
PH：6-8 Suspended solids inside the water≤50ppm
Chloride≤2501㎎/L
Total hardness≤450㎎/L
|
Water pressure：0.01-0.4Mpa
PH：6-8 Suspended solids inside the water≤50ppm
Chloride≤2501㎎/L
Total hardness≤450㎎/L
|
Water pressure：0.01-0.4Mpa
PH：6-8 Suspended solids inside the water≤50ppm
Chloride≤2501㎎/L
Total hardness≤450㎎/L
|
-
