Genset model |
HL500GF |
|
Genset rated power |
400KW/500KVA |
|
Rated voltage |
400/230V (adjustable) |
|
Rated current |
720 Amps |
|
Frequency |
50 Hz |
|
Power factor |
0.8 Lagging |
|
Connecting type |
3 phase 4 wire |
|
Cooling system |
Closed cycle water-cooled with fan, water tank |
|
Overall dimension (L×W×H) mm |
3540*1250*1830
|
|
Gross weight (kg) |
4000 |
|
Diesel Engine |
|
|
Brand |
YUCHAI |
|
Model |
YC6T660L-D20 |
|
Engine type |
6 cylinders vertical in Line, 4 stroke, |
|
Aspiration |
Turbocharged and intercooled |
|
Rotating speed |
1500 RPM |
|
Engine cooling system |
Water-cooled |
|
Fuel system |
Electronic control injection |
|
Starting method |
By 24V batteries |
|
Engine filter system |
Dry type air filter,fuel filter, oil filter, water filter |
|
Displacement(L) |
16.35 |
|
Bore×Stroke(mm) |
145×165 |
|
Compression ratio |
15:1 |
|
100% Load fuel consumption (l/h) |
≤192 |
|
Lube capacity(L) |
45 |
|
Alternator |
|
|
Brand |
SHANHUA |
|
Model |
HLF500 |
|
Excite type |
Brushless self-excited AVR regulation |
|
Connecting type |
3 phase 4 pole |
|
Steady frequency change |
0.50% |
|
No load voltage |
≥95%-105% |
|
Steady voltage |
≤±1% |
|
Insulation class |
Class H |
|
Protection grade |
IP23 |
